LWL Screen Scroll Centrifuge
Our LWL screen scroll centrifuge is a horizontal screw discharge filtering centrifuge supporting continuous feeding, washing and dewatering. With stable running, excellent washing effect, large handling capacity, and high economic efficiency, the machine can carry out continuous feeding, washing, dehydrating, and discharging of suspensions when running at full speed. It is highly efficient solid-liquid separation equipment. GMP-compliant design.
Quick Disassembly
Compact Design
General Settlement
Smooth Operation
Simple Structure
◆ Operating Principle
The LWL series centrifuge is a filtering centrifuge with horizontal screw discharge. With stable running, good washing effect, high handling capacity, and high economic efficiency, the machine can carry out continuous feeding, washing, dehydrating and discharging of suspensions when running at full speed. It is a piece of efficient separation equipment for solid–liquid separation.
◆ Main Features
● Continuous operation with the highest handling capacity.
● Wide application with various types of bowls and spiral rollers.
● Reasonable power configuration with low energy consumption.
● Parts that contact materials are made of austenitic stainless steel.
● Imported bearings, seals, and independent circulating oil lubrication system are adopted.
● The closed housing can protect the operator and site environment.
● Because of its small volume and convenient installation, there is no need to make any complex foundation.
● Safe and reliable running. The V type unloading and overload protective devices are adopted.
● Optional dual motor dual frequency conversion type.
● Dynamic adjustment of differential speed, wide range of use.
| Model | Drum Dia.(mm) | Capacity(m3/h) | Max. RPM(rpm) | Max. RCF(g) | Power(kw) | Weight(kg) | Overall Dimensions(mm) |
| LWL-250 | 250 | 0.5-0.8 | 3500 | 1700 | 4 | 500 | 1050*1100*850 |
| LWL-350 | 350 | 1-5 | 2800 | 1530 | 11 | 1200 | 1170*1360*1085 |
| LWL-450 | 450 | 2-8 | 2600 | 1700 | 22 | 1600 | 1800*1500*1315 |
| LWL-530 | 530 | 3-10 | 2000 | 1185 | 30 | 2200 | 1480*1920*1470 |
| LWL-630 | 630 | 5-15 | 1800 | 1140 | 37 | 3500 | 2140*1625*1530 |
| LWL-800 | 800 | 8-20 | 1500 | 1000 | 55 | 4500 | 2500*2200*1800 |
| LWL-1000 | 1000 | 10-30 | 900 | 450 | 75 | 6200 | 3200*2200*2300 |
